H-107xW Series - Forged DZR Brass In-Line Spring Check Valve On NIBCO

Products Systems Brands Resources CAD/BIM Solutions eServices Valves System Management Fittings Tools, Pipe & Accessories NIBCO Webstone® Join Our Team Core Values Life at NIBCO Locations System Control System Quality Temperature Control Metal Fittings Plastic Fittings Industrial Plastic Fittings 585HP NIBCO Press Systems Wrot Racer Push Fittings

Material Number	Connection Type	Valve Size	Cv Coefficient	Cracking Pressure
H-10741W	N/A FIP	N/A 3/8	N/A 2.40	N/A 1.45 psi
H-10742W	N/A FIP	N/A 1/2	N/A 3.78	N/A 1.00 psi
H-10743W	N/A FIP	N/A 3/4	N/A 6.65	N/A 0.75 psi
H-10744W	N/A FIP	N/A 1	N/A 9.20	N/A 0.50 psi
H-10745W	N/A FIP	N/A 1 1/4	N/A 14.90	N/A 0.40 psi
H-10746W	N/A FIP	N/A 1 1/2	N/A 20.90	N/A 0.30 psi
H-10747W	N/A FIP	N/A 2	N/A 34.50	N/A 0.15 psi
H-10751W	N/A SWT	N/A 3/8	N/A 2.00	N/A 1.50 psi
H-10752W	N/A SWT	N/A 1/2	N/A 2.80	N/A 1.00 psi
H-10753W	N/A SWT	N/A 3/4	N/A 5.70	N/A 0.75 psi
H-10754W	N/A SWT	N/A 1	N/A 8.70	N/A 0.50 psi
H-10755W	N/A SWT	N/A 1 1/4	N/A 14.70	N/A 0.40 psi
H-10756W	N/A SWT	N/A 1 1/2	N/A 20.50	N/A 0.30 psi
H-10757W	N/A SWT	N/A 2	N/A 34.40	N/A 0.15 psi

H-10741W

N/A FIP

N/A 3/8

N/A 2.40

N/A 1.45 psi

H-10742W

N/A FIP

N/A 1/2

N/A 3.78

N/A 1.00 psi

H-10743W

N/A FIP

N/A 3/4

N/A 6.65

N/A 0.75 psi

H-10744W

N/A FIP

N/A 1

N/A 9.20

N/A 0.50 psi

H-10745W

N/A FIP

N/A 1 1/4

N/A 14.90

N/A 0.40 psi

H-10746W

N/A FIP

N/A 1 1/2

N/A 20.90

N/A 0.30 psi

H-10747W

N/A FIP

N/A 2

N/A 34.50

N/A 0.15 psi

H-10751W

N/A SWT

N/A 3/8

N/A 2.00

N/A 1.50 psi

H-10752W

N/A SWT

N/A 1/2

N/A 2.80

N/A 1.00 psi

H-10753W

N/A SWT

N/A 3/4

N/A 5.70

N/A 0.75 psi

H-10754W

N/A SWT

N/A 1

N/A 8.70

N/A 0.50 psi

H-10755W

N/A SWT

N/A 1 1/4

N/A 14.70

N/A 0.40 psi

H-10756W

N/A SWT

N/A 1 1/2

N/A 20.50

N/A 0.30 psi

H-10757W

N/A SWT

N/A 2

N/A 34.40

N/A 0.15 psi
